fi-7300NX Scanner


SKU: PA03768-B005 Categories: , Tag:


Optimize your office with the fi-7300NX scanner.

Optimize your office space and place the scanner wherever you need, without the limitation of a cable. The fi-7300NX offers both WiFi and Ethernet connectivity so the scanner can now be set up anywhere to improve worker productivity and reduce interruptions.

The fi-7300NX is perfect for the enterprise that wants to reduce costs with PC-less scanning and realize fast ROI. You no longer need a local PC, monitor, or keyboard. Integrated WiFi allows premium placement in hard-to-reach, high-traffic areas without having to pay for expensive Ethernet cabling.

Because it doesn’t need to be tied to any user’s PC, users can capture and review their documents on any deployed fi-7300NX scanner without interrupting other employees.

Using a Windows Server, PaperStream NX Manager provides easy-to-use, web-based, centralized management, allowing IT professional to remotely control and administer workflows. Control up to 1,000 scanners, even at remote branches and offices via VPN.

• Customize  each scanner with unique job sets based on location, department, or other criteria

• Job codes or PINs allow just the right access per user, providing only the scanning options available to that user and routing the scans to the correct workflow

• Microsoft Active Directory login allows users to authenticate with their familiar Windows username and password; therefore separate credentials needed to scan

• NFC card authentication toolkit allows login with a variety of common badge types, allowing users to log in and start scanning with just a tap of their ID card

• Scan directly to email, SharePoint Online, FTP/SFTP or folder. Integrations add support for scanning to cloud, server, and web-based systems

Seamless Integration Into Business Systems

Users can begin scanning from the touchscreen or from various applications on smart devices. Not only is direct data transfer to client-unique web systems possible with SDK use, but you can transfer secure data as a result of strong data encryption.

Scan Without the Computer

Users can scan and save documents without a local computer. They can simply login to the scanner using user authentication and select a job from their personalized menus on the touchscreen. Customized job menus ensure efficient and secure decentralized data entry is possible for each user.

The fi-7300NX supports NFC (Type-A and Type-B) authentication and user authentication with username and password input on the touch screen. It is also possible for different job menus to be assigned to each scanner, and avoid any authentication processes.

Scan from your smart device to any business platform

With PaperStream NX Manager, users can scan from mobile or web applications opened up on smart devices or thin client terminals. Seamless integration into company systems enables use of a variety of devices for scanning operations.

Additional information

Weight15.8 lbs
Dimensions11.8 × 7.9 × 6.6 in


• Scanner Type: ADF (Automatic Document Feeder), Duplex

• Scanning Speed (A4 Portrait, Simplex): 60 ppm (200/300 dpi)

• Scanning Speed (A4 Portrait, Duplex): 120 ipm (200/300 dpi)

• Image Sensor Type: Color CCD (Charge-Coupled Device) x 2 (front x 1, back x 1)

• Light Source: White LED Array x 2 (front x 1, back x 1)

• Optical Resolution: 600 dpi

• Output Resolution: 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver)

• Output Format: Color: 24-bit; Grayscale: 8-bit; Monochrome: 1-bit

• Background Colors: White/Black (selectable)

• Document Size (Minimum): 50.8 x 54 mm (2” x 2.1”)

• Document Size (Maximum): 216 x 355.6 mm (8.5” x 14”)

• Document Size (Long Paper Scanning): 5,588 mm (220”)

• Paper Weight (Thickness): 27 to 413 g/m² (7.2 to 110 lb

• Plastic Card Weight (Thickness): 1.4 mm (0.055”) or less

• ADF Capacity: 80 sheets (A4 80 g/m² or Letter 20 lb)

• Typical Daily Duty Cycle: 4,000 sheets

• Multifeed Detection: Overlap Detection (Ultrasonic Sensor), Length Detection

• Paper Protection: Lag Detection, Sound Detection (iSOP)

• Display: 4.3” TFT Color Touchscreen

• Authentication: Keyboard (on touchscreen), NFC

• Interface: USB 3.1 Gen1 / USB 3.0 / USB 2.0 / USB 1.1

• Network Interface: 10BASE-T, 100BASE-TX, 1000BASE-T

• Network Protocols: IPv4(15), TCP, UDP, ICMP, DHCP, HTTP/HTTPS, DNS

• Power Requirement: AC 100 to 240 V ±10 %

• Power Consumption: 42 W or less

• Supported Operating System: Windows 10 (32-bit/64-bit), Windows 8.1 (32-bit/64-bit), Windows 7 (32-bit/64-bit), Windows Server 2016 (64-bit), Windows Server 2012 R2 (64-bit), Windows Server 2012 (64-bit), Windows Server 2008 R2 (64-bit), Windows Server 2008 (32-bit/64-bit)

• Inbox Contents: Chuter Unit, AC Cable, AC Adapter, USB Cable, Setup DVD-ROM

Download Data Sheet

Download Data Sheet
